Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
Variant-specific documents are available under details in the overview below.
IP rating
IP 20
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Spreading angle [°]
6 - 60
Light source
LED (built-in)
Optics
Clear
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
Assembly
Shine
Art. No. 101140 - 660 - 2
Effekt [W]:
20
CRI [>]:
80
Kelvin [K]:
3000
Lysstyring:
3-circuit
Lysspredning [°]:
6 - 60
Farge:
Black
Diffusor:
Clear
Lumen LED (Tc=25):
950
101140 - 660 - 2
20
80
3000
3-circuit
6 - 60
Black
Clear
950
Assortment status: Order item
Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
IP rating
IP 20
Color
Black
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Lumens LED (tc=25)
950
Spreading angle [°]
6 - 60
Color temperature [K]
3000
Color rendering [CRI/Ra]
80
Color code
830
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
No
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
20
Connection
3-circuit
Assembly
Shine
Art. No. 101141 - 660 - 2 -ddd
Effekt [W]:
20
CRI [>]:
90
Kelvin [K]:
2700
Lysstyring:
Rail 3-circuit+dim
Lysspredning [°]:
6 - 60
Farge:
Black
Diffusor:
Clear
Lumen LED (Tc=25):
1750
101141 - 660 - 2 -ddd
20
90
2700
Rail 3-circuit+dim
6 - 60
Black
Clear
1750
Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
IP rating
IP 20
Color
Black
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Lumens LED (tc=25)
1750
Spreading angle [°]
6 - 60
Color temperature [K]
2700
Color rendering [CRI/Ra]
90
Color code
927
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
DALI2
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
20
Max. load per course - B10
26
Max. load per course - B16
42
Max. load per course - C10
45
Max. load per course - C16
71
Starting current Imax [A]
35
Starting current time [µs]
80
Strøm LED [mA]
500
Voltage out, min. [V]
35
Voltage out, max. [V]
40
Connection
Rail 3-circuit+dim
Assembly
Shine
Art. No. 101141 - 660 - 2 -p
Effekt [W]:
20
CRI [>]:
90
Kelvin [K]:
2700
Lysstyring:
3-circuit
Lysspredning [°]:
6 - 60
Farge:
Black
Diffusor:
Clear
Lumen LED (Tc=25):
1750
101141 - 660 - 2 -p
20
90
2700
3-circuit
6 - 60
Black
Clear
1750
Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
IP rating
IP 20
Color
Black
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Lumens LED (tc=25)
1750
Spreading angle [°]
6 - 60
Color temperature [K]
2700
Color rendering [CRI/Ra]
90
Color code
927
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Phase section
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
20
Max. load per course - B10
28
Max. load per course - B16
46
Max. load per course - C10
28
Max. load per course - C16
46
Starting current Imax [A]
15
Starting current time [µs]
40
Strøm LED [mA]
500
Voltage out, min. [V]
35
Voltage out, max. [V]
40
Connection
3-circuit
Assembly
Shine
Art. No. 101141 - 660 - 3 -ddd
Effekt [W]:
20
CRI [>]:
90
Kelvin [K]:
2700
Lysstyring:
Rail 3-circuit+dim
Lysspredning [°]:
6 - 60
Farge:
White
Diffusor:
Clear
Lumen LED (Tc=25):
1750
101141 - 660 - 3 -ddd
20
90
2700
Rail 3-circuit+dim
6 - 60
White
Clear
1750
Assortment status: Order item
Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
IP rating
IP 20
Color
White
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Lumens LED (tc=25)
1750
Spreading angle [°]
6 - 60
Color temperature [K]
2700
Color rendering [CRI/Ra]
90
Color code
927
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
DALI2
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
20
Max. load per course - B10
26
Max. load per course - B16
42
Max. load per course - C10
45
Max. load per course - C16
71
Starting current Imax [A]
35
Starting current time [µs]
80
Strøm LED [mA]
500
Voltage out, min. [V]
35
Voltage out, max. [V]
40
Connection
Rail 3-circuit+dim
Assembly
Shine
Art. No. 101141 - 660 - 3 -p
Effekt [W]:
20
CRI [>]:
90
Kelvin [K]:
2700
Lysstyring:
3-circuit
Lysspredning [°]:
6 - 60
Farge:
White
Diffusor:
Clear
Lumen LED (Tc=25):
1750
101141 - 660 - 3 -p
20
90
2700
3-circuit
6 - 60
White
Clear
1750
Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
IP rating
IP 20
Color
White
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Lumens LED (tc=25)
1750
Spreading angle [°]
6 - 60
Color temperature [K]
2700
Color rendering [CRI/Ra]
90
Color code
927
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Phase section
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
20
Max. load per course - B10
28
Max. load per course - B16
46
Max. load per course - C10
28
Max. load per course - C16
46
Starting current Imax [A]
15
Starting current time [µs]
40
Strøm LED [mA]
500
Voltage out, min. [V]
35
Voltage out, max. [V]
40
Connection
3-circuit
Assembly
Shine
Art. No. 101142 - 660 - 2 -ddd
Effekt [W]:
20
CRI [>]:
90
Kelvin [K]:
3000
Lysstyring:
Rail 3-circuit+dim
Lysspredning [°]:
6 - 60
Farge:
Black
Diffusor:
Clear
Lumen LED (Tc=25):
1850
101142 - 660 - 2 -ddd
20
90
3000
Rail 3-circuit+dim
6 - 60
Black
Clear
1850
Assortment status: In stock
Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
IP rating
IP 20
Color
Black
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Lumens LED (tc=25)
1850
Spreading angle [°]
6 - 60
Color temperature [K]
3000
Color rendering [CRI/Ra]
90
Color code
930
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
DALI2
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
20
Max. load per course - B10
26
Max. load per course - B16
42
Max. load per course - C10
45
Max. load per course - C16
71
Starting current Imax [A]
35
Starting current time [µs]
80
Strøm LED [mA]
500
Voltage out, min. [V]
35
Voltage out, max. [V]
40
Connection
Rail 3-circuit+dim
Assembly
Shine
Art. No. 101142 - 660 - 2 -p
Effekt [W]:
20
CRI [>]:
90
Kelvin [K]:
3000
Lysstyring:
3-circuit
Lysspredning [°]:
6 - 60
Farge:
Black
Diffusor:
Clear
Lumen LED (Tc=25):
1850
101142 - 660 - 2 -p
20
90
3000
3-circuit
6 - 60
Black
Clear
1850
Assortment status: In stock
Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
IP rating
IP 20
Color
Black
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Lumens LED (tc=25)
1850
Spreading angle [°]
6 - 60
Color temperature [K]
3000
Color rendering [CRI/Ra]
90
Color code
930
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Phase section
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
20
Max. load per course - B10
28
Max. load per course - B16
46
Max. load per course - C10
28
Max. load per course - C16
46
Starting current Imax [A]
15
Starting current time [µs]
40
Strøm LED [mA]
500
Voltage out, min. [V]
35
Voltage out, max. [V]
40
Connection
3-circuit
Assembly
Shine
Art. No. 101142 - 660 - 3 -ddd
Effekt [W]:
20
CRI [>]:
90
Kelvin [K]:
3000
Lysstyring:
Rail 3-circuit+dim
Lysspredning [°]:
6 - 60
Farge:
White
Diffusor:
Clear
Lumen LED (Tc=25):
1850
101142 - 660 - 3 -ddd
20
90
3000
Rail 3-circuit+dim
6 - 60
White
Clear
1850
Assortment status: Order item
Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
IP rating
IP 20
Color
White
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Lumens LED (tc=25)
1850
Spreading angle [°]
6 - 60
Color temperature [K]
3000
Color rendering [CRI/Ra]
90
Color code
930
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
DALI2
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
20
Max. load per course - B10
26
Max. load per course - B16
42
Max. load per course - C10
45
Max. load per course - C16
71
Starting current Imax [A]
35
Starting current time [µs]
80
Strøm LED [mA]
500
Voltage out, min. [V]
35
Voltage out, max. [V]
40
Connection
Rail 3-circuit+dim
Assembly
Shine
Art. No. 101142 - 660 - 3 -p
Effekt [W]:
20
CRI [>]:
90
Kelvin [K]:
3000
Lysstyring:
3-circuit
Lysspredning [°]:
6 - 60
Farge:
White
Diffusor:
Clear
Lumen LED (Tc=25):
1850
101142 - 660 - 3 -p
20
90
3000
3-circuit
6 - 60
White
Clear
1850
Zoom is a relatively small spotlight for use in track systems. The unique zoom patent makes it possible to vary the angle of the light beam from 6 to 60 degrees. This variation makes Zoom a very versatile spotlight.
The design is made of robust cast aluminum, and Zoom comes in both black and white versions.
IP rating
IP 20
Color
White
Length [mm]
158
Diameter [mm]
85
Weight [kg]
1
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Lumens LED (tc=25)
1850
Spreading angle [°]
6 - 60
Color temperature [K]
3000
Color rendering [CRI/Ra]
90
Color code
930
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Phase section
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
20
Max. load per course - B10
28
Max. load per course - B16
46
Max. load per course - C10
28
Max. load per course - C16
46
Starting current Imax [A]
15
Starting current time [µs]
40
Strøm LED [mA]
500
Voltage out, min. [V]
35
Voltage out, max. [V]
40
Connection
3-circuit
Assembly
Shine
