Flare 40 is a variant spotlight that fits our Evo 48V track system.
With 6.6W, high light output and color rendering, this is perfect for homes, shops, restaurants, hotels and office environments.
The spotlight can be easily adjusted in all directions to meet different needs. It can be tilted 90 degrees and rotated 350 degrees around its own axis.
Variant-specific documents are available under details in the overview below.
IP rating
IP 20
Length [mm]
105
Diameter [mm]
40
Dimming type
DALI, DALI2
Voltage [V]
48VDC
Insulation class
3
Base
NOW
Connection
Rail EVO 48V
Assembly
Shine
Art. No. 101475 - 35 - 2 -ddd
Power [W]:
6,6
CRI [>]:
90
Kelvin [K]:
2700
Lighting control:
Rail EVO 48V
Light spread [°]:
35°
Color:
Black
Lumens LED (Tc=25):
640
101475 - 35 - 2 -ddd
6,6
90
2700
Rail EVO 48V
35°
Black
640
Assortment status: In stock
Flare 40 is a variant spotlight that fits our Evo 48V track system.
With 6.6W, high light output and color rendering, this is perfect for homes, shops, restaurants, hotels and office environments.
The spotlight can be easily adjusted in all directions to meet different needs. It can be tilted 90 degrees and rotated 350 degrees around its own axis.
IP rating
IP 20
Color
Black
Length [mm]
105
Width [mm]
40
Diameter [mm]
40
Lumen out [lm]
640
Lumens LED (tc=25)
640
Spreading angle [°]
35°
Color temperature [K]
2700
Color rendering [CRI/Ra]
90
Color code
927
Color Tolerance [SDCM]
3
Dimming type
DALI
Voltage [V]
48VDC
Insulation class
3
Base
NOW
System power [W]
6,6
Luminous efficacy [lm/W]
97
LED current [mA]
700
Voltage out, min. [V]
8.6
Voltage out, max. [V]
10.2
Connection
Rail EVO 48V
Assembly
Shine
Art. No. 101475 - 35 - 3 -ddd
Power [W]:
6,6
CRI [>]:
90
Kelvin [K]:
2700
Lighting control:
Rail EVO 48V
Light spread [°]:
35°
Color:
White
Lumens LED (Tc=25):
640
101475 - 35 - 3 -ddd
6,6
90
2700
Rail EVO 48V
35°
White
640
Assortment status: In stock
Flare 40 is a variant spotlight that fits our Evo 48V track system.
With 6.6W, high light output and color rendering, this is perfect for homes, shops, restaurants, hotels and office environments.
The spotlight can be easily adjusted in all directions to meet different needs. It can be tilted 90 degrees and rotated 350 degrees around its own axis.
IP rating
IP 20
Color
White
Length [mm]
105
Width [mm]
40
Diameter [mm]
40
Lumen out [lm]
640
Lumens LED (tc=25)
640
Spreading angle [°]
35°
Color temperature [K]
2700
Color rendering [CRI/Ra]
90
Color code
927
Color Tolerance [SDCM]
3
Dimming type
DALI
Voltage [V]
48VDC
Insulation class
3
Base
NOW
System power [W]
6,6
Luminous efficacy [lm/W]
97
LED current [mA]
700
Voltage out, min. [V]
8.6
Voltage out, max. [V]
10.2
Connection
Rail EVO 48V
Assembly
Shine
Art. No. 101476 - 35 - 2 -ddd
Power [W]:
6,6
CRI [>]:
90
Kelvin [K]:
3000
Lighting control:
Rail EVO 48V
Light spread [°]:
35°
Color:
Black
Lumens LED (Tc=25):
670
101476 - 35 - 2 -ddd
6,6
90
3000
Rail EVO 48V
35°
Black
670
Assortment status: In stock
Flare 40 is a variant spotlight that fits our Evo 48V track system.
With 6.6W, high light output and color rendering, this is perfect for homes, shops, restaurants, hotels and office environments.
The spotlight can be easily adjusted in all directions to meet different needs. It can be tilted 90 degrees and rotated 350 degrees around its own axis.
IP rating
IP 20
Color
Black
Length [mm]
105
Width [mm]
40
Diameter [mm]
40
Lumen out [lm]
670
Lumens LED (tc=25)
670
Spreading angle [°]
35°
Color temperature [K]
3000
Color rendering [CRI/Ra]
90
Color code
930
Color Tolerance [SDCM]
3
Dimming type
DALI
Voltage [V]
48VDC
Insulation class
3
Base
NOW
System power [W]
6,6
Luminous efficacy [lm/W]
101
LED current [mA]
700
Voltage out, min. [V]
8.6
Voltage out, max. [V]
10.2
Connection
Rail EVO 48V
Assembly
Shine
Art. No. 101476 - 35 - 3 -ddd
Power [W]:
6,6
CRI [>]:
9
Kelvin [K]:
3000
Lighting control:
Rail EVO 48V
Light spread [°]:
35°
Color:
White
Lumens LED (Tc=25):
670
101476 - 35 - 3 -ddd
6,6
9
3000
Rail EVO 48V
35°
White
670
Assortment status: In stock
Flare 40 is a variant spotlight that fits our Evo 48V track system.
With 6.6W, high light output and color rendering, this is perfect for homes, shops, restaurants, hotels and office environments.
The spotlight can be easily adjusted in all directions to meet different needs. It can be tilted 90 degrees and rotated 350 degrees around its own axis.
IP rating
IP 20
Color
White
Length [mm]
105
Width [mm]
40
Diameter [mm]
40
Lumen out [lm]
670
Lumens LED (tc=25)
670
Spreading angle [°]
35°
Color temperature [K]
3000
Color rendering [CRI/Ra]
9
Color code
930
Color Tolerance [SDCM]
3
Dimming type
DALI
Voltage [V]
48VDC
Insulation class
3
Base
NOW
System power [W]
6,6
Luminous efficacy [lm/W]
101
LED current [mA]
700
Voltage out, min. [V]
8.6
Voltage out, max. [V]
10.2
Connection
Rail EVO 48V
Assembly
Shine
