Product info
SPECIFICATIONS
Product
IP rating
IP66
Vandal class
IK08
Color
Gray
Length [mm]
663
Width [mm]
347
Height [mm]
685
Weight [kg]
31.9
Lifetime [h]
L90B10: 100,000
Operating temperature [°C]
-30 - 50
LIGHTING
Lumen out [lm]
277200
Lumen LED (tc=25)
277200
Spreading angle [°]
26x134
Color temperature [K]
5700
Color rendering [CRI/Ra]
70
Color code
757
Color Tolerance [SDCM]
5
Light source
LED (built-in)
Optics
Lens
ELECTRICAL DATA
Dimming type
DALI2, 0-10V, DMX
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
1
System power [W]
1800
Luminous efficacy [lm/W]
154
Strøm LED [mA]
630
Voltage out, min. [V]
2.7
Voltage out, max. [V]
3.2
ASSEMBLY / CONNECTION
Connection
Terminal
Assembly
Wall, Mast
