Cold 10 Mini

  • Light output : Available with CRI90 and choice of 2700K or 3000K

  • Dimming: Comes with phase-separated dimming

  • Easy installation : Designed for recessed ceiling mounting

Read more

Show variants
Category:
IP20: Indoor use.IK00: No impact protection.Insulation class 2: Double insulated and should not be connected to ground.Application: Indoor

Product info

DESCRIPTION

Cold 10 Mini is an elegant and recessed downlight , perfect for a variety of applications including cafes, lodges, general rooms, hotels, homes and shops. With a hole size of 189x27mm and phase section, this downlight offers exceptional flexibility. With an IP20 rating and protection class 2, as well as a lifetime of L80B10: 100,000 hours, it ensures Cold 10 Mini long-lasting and reliable performance. Its black RAL9003 finish and slim design make it a stylish addition to any interior.

Documentation

Family data sheet All files (ZIP)

Variant-specific documents are available under details in the overview below.

SPECIFICATIONS

Product

IP rating

IP20

Vandal class

IK00

Length [mm]

196

Width [mm]

33

Height [mm]

50

Lifetime [h]

L80B10: 100,000

LIGHTING

Light source

LED (built-in)

Optics

NOW

ELECTRICAL DATA

Dimming type

Phase section

Voltage [V]

230V 50Hz

Insulation class

2

System power [W]

2x10.5

ASSEMBLY / CONNECTION

Recess [mm]

189*27

Assembly

Recessed, Ceiling

OPTIONS

Power [W]
Lumen LED (Tc=25)
Kelvin [K]
CRI [>]
Light spread [°]
Color
Diffuser
Lighting control
Art. No. Power [W] Lumen LED (Tc=25) Kelvin [K] CRI [>] Light distribution [°] Color Diffuser Light control
Energy labeling
Cold 10 Minis

Cold 10 Mini 2000lm 930 50° 10x2,1W BK Phasecut

Art. No. 1111-50-2

Power [W]:

21

Lumen LED (Tc=25):

2000

Kelvin [K]:

3000

CRI [>]:

90

Light spread [°]:

50°

Color:

Black

Diffuser:

NOW

Lighting control:

EPN0024

1111-50-2

21

2000

3000

90

50°

Black

NOW

EPN0024

February

Product data sheet

February

Product data sheet

Cold 10 Minis

Assortment status: In stock

DIMENSIONS AND LIGHT DISTRIBUTION

DOCUMENTATION

Datasheet FDV Light file (.ldt) All files (ZIP)
CE markedIP20: Indoor use.IK00: No impact protection.Insulation class 2: Double insulated and should not be connected to ground.Application: Indoor

Cold 10 Mini is an elegant and recessed downlight , perfect for a variety of applications including cafes, lodges, general rooms, hotels, homes and shops. With a hole size of 189x27mm and phase section, this downlight offers exceptional flexibility. With an IP20 rating and protection class 2, as well as a lifetime of L80B10: 100,000 hours, it ensures Cold 10 Mini long-lasting and reliable performance. Its black RAL9003 finish and slim design make it a stylish addition to any interior.

Product

IP rating

IP20

Vandal class

IK00

Color

Black

Length [mm]

196

Width [mm]

33

Height [mm]

50

Weight [kg]

0.54

Material

Aluminum

Lifetime [h]

L80B10: 100,000

LIGHTING

Lumen out [lm]

1390.4

Lumen LED (tc=25)

2000

Spreading angle [°]

50°

Color temperature [K]

3000

Color rendering [CRI/Ra]

90

Color code

927

Light source

LED (built-in)

Optics

NOW

ELECTRICAL DATA

Dimming type

Phase section

Flicker-free

No

Voltage [V]

230V 50Hz

Insulation class

2

System power [W]

21

Luminous efficacy [lm/W]

58

Max. load per course - B10

35

Max. load per course - B16

56

Max. load per course - C10

52

Max. load per course - C16

84

Leakage current [mA]

0.7

Starting current Imax [A]

5

Starting current time [µs]

300

Strøm LED [mA]

7

Voltage out, min. [V]

27

Voltage out, max. [V]

32

ASSEMBLY / CONNECTION

Connection

EPN0024

Recess [mm]

189*27

Assembly

Recessed, Ceiling

Cold 10 Minis

Cold 10 Mini 1900lm 927 50° 10x2,1W BK Phasecut

Art. No. 1112-50-2

Power [W]:

21

Lumen LED (Tc=25):

1900

Kelvin [K]:

2700

CRI [>]:

90

Light spread [°]:

50°

Color:

Black

Diffuser:

NOW

Lighting control:

EPN0024

1112-50-2

21

1900

2700

90

50°

Black

NOW

EPN0024

February

Product data sheet

February

Product data sheet

Cold 10 Minis

Assortment status: In stock

DIMENSIONS AND LIGHT DISTRIBUTION

DOCUMENTATION

Datasheet FDV Light file (.ldt) All files (ZIP)
CE markedIP20: Indoor use.IK00: No impact protection.Insulation class 2: Double insulated and should not be connected to ground.Application: Indoor

Cold 10 Mini is an elegant and recessed downlight , perfect for a variety of applications including cafes, lodges, general rooms, hotels, homes and shops. With a hole size of 189x27mm and phase section, this downlight offers exceptional flexibility. With an IP20 rating and protection class 2, as well as a lifetime of L80B10: 100,000 hours, it ensures Cold 10 Mini long-lasting and reliable performance. Its black RAL9003 finish and slim design make it a stylish addition to any interior.

Product

IP rating

IP20

Vandal class

IK00

Color

Black

Length [mm]

196

Width [mm]

33

Height [mm]

50

Weight [kg]

0.54

Material

Aluminum

Lifetime [h]

L80B10: 100,000

LIGHTING

Lumen out [lm]

1218

Lumen LED (tc=25)

1900

Spreading angle [°]

50°

Color temperature [K]

2700

Color rendering [CRI/Ra]

90

Color code

927

Light source

LED (built-in)

Optics

NOW

ELECTRICAL DATA

Dimming type

Phase section

Flicker-free

No

Voltage [V]

230V 50Hz

Insulation class

2

System power [W]

21

Luminous efficacy [lm/W]

51

Max. load per course - B10

35

Max. load per course - B16

56

Max. load per course - C10

52

Max. load per course - C16

84

Leakage current [mA]

0.7

Starting current Imax [A]

5

Starting current time [µs]

300

Strøm LED [mA]

7

Voltage out, min. [V]

27

Voltage out, max. [V]

32

ASSEMBLY / CONNECTION

Connection

EPN0024

Recess [mm]

189*27

Assembly

Recessed, Ceiling
