Colonel

  • Floodlights for outdoor use

  • Cast aluminum construction

  • Power from 29W to 65W

Read more

Show variants
Category:
CE markedIP66 - High pressure water jet proof: Protected against high pressure water jets from all directions, as well as being dustproof. Well suited for outdoor use.IK10: Protection against impact equivalent to 5kg from a height of 400mm.Insulation class 1: Must be connected to ground.Application: Approved for outdoor use

Product info

DESCRIPTION

Colonel is a powerful floodlight designed specifically for outdoor use. Made of die-cast aluminum with IP66 certification, it provides reliable lighting in harsh weather conditions. The vacuum inside prevents condensation. With power from 29W to 65W and a clear lens, Colonel offers outstanding performance and durability. Supplied with a mounting bracket and 50 cm open-ended cable for easy installation. Colonel is a reliable choice for lighting outdoor areas in need of reliable and durable lighting

Documentation

Family data sheet All files (ZIP)

Variant-specific documents are available under details in the overview below.

SPECIFICATIONS

Product

IP-grad

IP66

Vandal klasse

IK10

Levetid [t]

L80B50: 50,000

Driftstemperatur [°C]

-40 - 55

LIGHTING

Optikk

Clear

ELECTRICAL DATA

Dimmetype

1-10V

Spenning [V]

230V 50Hz

Isolasjonsklasse

1

Sokkel

NOW

ASSEMBLY / CONNECTION

Montering

Surface-mounted, Wall, Ceiling, Floor

OPTIONS

Power [W]
Base
Kelvin [K]
CRI [>]
Light spread [°]
Color
Diffuser
Lighting control
Lumen LED (Tc=25)
Art. No. Power [W] Base Kelvin [K] CRI [>] Light distribution [°] Color Diffuser Light control Lumen LED (Tc=25)
Energy labeling

Colonel

Art. No. 3911-2-03-2

Effekt [W]:

29

Sokkel:

N/A

Kelvin [K]:

4000

CRI [>]:

80

Lysspredning [°]:

110x90°

Farge:

Sort/Brun

Diffusor:

Klar

Lysstyring:

Kabel 2m

Lumen LED (Tc=25):

4700

3911-2-03-2

29

NOW

4000

80

110x90°

Black/Brown

Clear

Cable 2m

4700

A+

Product data sheet

A+

Product data sheet

Assortment status: Order item

DIMENSIONS AND LIGHT DISTRIBUTION

DOCUMENTATION

Datasheet FDV Energy labeling All files (ZIP)
CE markedIP66 - High pressure water jet proof: Protected against high pressure water jets from all directions, as well as being dustproof. Well suited for outdoor use.IK10: Protection against impact equivalent to 5kg from a height of 400mm.Insulation class 1: Must be connected to ground.Application: Approved for outdoor use

Colonel is a powerful floodlight designed specifically for outdoor use. Made of die-cast aluminum with IP66 certification, it provides reliable lighting in harsh weather conditions. The vacuum inside prevents condensation. With power from 29W to 65W and a clear lens, Colonel offers outstanding performance and durability. Supplied with a mounting bracket and 50 cm open-ended cable for easy installation. Colonel is a reliable choice for lighting outdoor areas in need of reliable and durable lighting

Product

IP-grad

IP66

Vandal klasse

IK10

Farge

Black/Brown

Lengde [mm]

189

Bredde [mm]

53

Høyde [mm]

120

Vekt [kg]

1.2

Levetid [t]

L80B50: 50,000

Driftstemperatur [°C]

-40 - 55

LIGHTING

Lumen ut [lm]

3750

Lumen LED (tc=25)

4700

Spredningsvinkel [°]

110x90°

Fargetemperatur [K]

4000

Fargegjengivelse [CRI/Ra]

80

Fargekode

840

Optikk

Clear

ELECTRICAL DATA

Dimmetype

1-10V

Spenning [V]

230V 50Hz

Isolasjonsklasse

1

Sokkel

NOW

Systemeffekt [W]

29

Lyseffekt [lm/W]

129

ASSEMBLY / CONNECTION

Tilkobling

Cable 2m

Montering

Surface-mounted, Wall, Ceiling, Floor

Colonel

Art. No. 3912-2-03-2

Effekt [W]:

40

Sokkel:

N/A

Kelvin [K]:

4000

CRI [>]:

80

Lysspredning [°]:

110x90°

Farge:

Sort/Brun

Diffusor:

Klar

Lysstyring:

Kabel 2m

Lumen LED (Tc=25):

6600

3912-2-03-2

40

NOW

4000

80

110x90°

Black/Brown

Clear

Cable 2m

6600

A+

Product data sheet

A+

Product data sheet

Assortment status: Order item

DIMENSIONS

DOCUMENTATION

Datasheet FDV Energy labeling All files (ZIP)
CE markedIP66 - High pressure water jet proof: Protected against high pressure water jets from all directions, as well as being dustproof. Well suited for outdoor use.IK10: Protection against impact equivalent to 5kg from a height of 400mm.Insulation class 1: Must be connected to ground.Application: Approved for outdoor use

Colonel is a powerful floodlight designed specifically for outdoor use. Made of die-cast aluminum with IP66 certification, it provides reliable lighting in harsh weather conditions. The vacuum inside prevents condensation. With power from 29W to 65W and a clear lens, Colonel offers outstanding performance and durability. Supplied with a mounting bracket and 50 cm open-ended cable for easy installation. Colonel is a reliable choice for lighting outdoor areas in need of reliable and durable lighting

Product

IP-grad

IP66

Vandal klasse

IK10

Farge

Black/Brown

Lengde [mm]

216

Bredde [mm]

62

Høyde [mm]

150

Vekt [kg]

1.8

Levetid [t]

L80B50: 50,000

Driftstemperatur [°C]

-40 - 55

LIGHTING

Lumen ut [lm]

4940

Lumen LED (tc=25)

6600

Spredningsvinkel [°]

110x90°

Fargetemperatur [K]

4000

Fargegjengivelse [CRI/Ra]

80

Fargekode

840

Optikk

Clear

ELECTRICAL DATA

Dimmetype

1-10V

Spenning [V]

230V 50Hz

Isolasjonsklasse

1

Sokkel

NOW

Systemeffekt [W]

40

Lyseffekt [lm/W]

123

ASSEMBLY / CONNECTION

Tilkobling

Cable 2m

Montering

Surface-mounted, Wall, Ceiling, Floor

Colonel

Art. No. 3913-03-2

Effekt [W]:

50

Sokkel:

N/A

Kelvin [K]:

4000

CRI [>]:

80

Lysspredning [°]:

110x90°

Farge:

Sort/Brun

Diffusor:

Klar

Lysstyring:

Kabel 0.5m

Lumen LED (Tc=25):

8000

3913-03-2

50

NOW

4000

80

110x90°

Black/Brown

Clear

Cable 0.5m

8000

A+

Product data sheet

A+

Product data sheet

Assortment status: Order item

DIMENSIONS AND LIGHT DISTRIBUTION

DOCUMENTATION

Datasheet FDV Energy labeling Light file (.ldt) All files (ZIP)
CE markedIP66 - High pressure water jet proof: Protected against high pressure water jets from all directions, as well as being dustproof. Well suited for outdoor use.IK10: Protection against impact equivalent to 5kg from a height of 400mm.Insulation class 1: Must be connected to ground.Application: Approved for outdoor use

Colonel is a powerful floodlight designed specifically for outdoor use. Made of die-cast aluminum with IP66 certification, it provides reliable lighting in harsh weather conditions. The vacuum inside prevents condensation. With power from 29W to 65W and a clear lens, Colonel offers outstanding performance and durability. Supplied with a mounting bracket and 50 cm open-ended cable for easy installation. Colonel is a reliable choice for lighting outdoor areas in need of reliable and durable lighting

Product

IP-grad

IP66

Vandal klasse

IK10

Farge

Black/Brown

Lengde [mm]

216

Bredde [mm]

62

Høyde [mm]

150

Vekt [kg]

1.8

Levetid [t]

L80B50: 50,000

Driftstemperatur [°C]

-40 - 55

LIGHTING

Lumen ut [lm]

6151

Lumen LED (tc=25)

8000

Spredningsvinkel [°]

110x90°

Fargetemperatur [K]

4000

Fargegjengivelse [CRI/Ra]

80

Fargekode

840

Optikk

Clear

ELECTRICAL DATA

Dimmetype

1-10V

Spenning [V]

230V 50Hz

Isolasjonsklasse

1

Sokkel

NOW

Systemeffekt [W]

50

Lyseffekt [lm/W]

123

Maks. belastning pr. kurs - B10

7

Maks. belastning pr. kurs - B16

11

Maks. belastning pr. kurs - C10

8

Maks. belastning pr. kurs - C16

13

Lekkasjestrøm [mA]

1

Startstrøm Imax [A]

50

Startstrøm tid [µs]

5

ASSEMBLY / CONNECTION

Tilkobling

Cable 0.5m

Montering

Surface-mounted, Wall, Ceiling, Floor

Colonel

Art. No. 3916-03-2

Sokkel:

N/A

Diffusor:

Klar

3916-03-2

NOW

Clear

A+

Product data sheet

A+

Product data sheet

Assortment status: Order item

DOCUMENTATION

Datasheet FDV Energy labeling All files (ZIP)
CE markedIP66 - High pressure water jet proof: Protected against high pressure water jets from all directions, as well as being dustproof. Well suited for outdoor use.IK10: Protection against impact equivalent to 5kg from a height of 400mm.Insulation class 1: Must be connected to ground.Application: Approved for outdoor use

Colonel is a powerful floodlight designed specifically for outdoor use. Made of die-cast aluminum with IP66 certification, it provides reliable lighting in harsh weather conditions. The vacuum inside prevents condensation. With power from 29W to 65W and a clear lens, Colonel offers outstanding performance and durability. Supplied with a mounting bracket and 50 cm open-ended cable for easy installation. Colonel is a reliable choice for lighting outdoor areas in need of reliable and durable lighting

Product

IP-grad

IP66

Vandal klasse

IK10

Levetid [t]

L80B50: 50,000

Driftstemperatur [°C]

-40 - 55

LIGHTING

Optikk

Clear

ELECTRICAL DATA

Dimmetype

1-10V

Spenning [V]

230V 50Hz

Isolasjonsklasse

1

Sokkel

NOW

ASSEMBLY / CONNECTION

Montering

Surface-mounted, Wall, Ceiling, Floor
