Cylinder 60 Spotskinnepakke X2, 1M, Dim-to-Warm, hvit

  • High performance: Powerful light, high color rendering and 100,000 h lifespan

  • Flexible: 90° angle, 350° rotation and movable on rail

  • Dim-to-Warm 3000–2000K , phase cut dimming

Read more
Product number: 103430-07 Assortment status: Backorder item Category: Tag:
IP20: Indoor use.Insulation class 1: Must be connected to ground.Application: IndoorDim2Warm: Provides warm light at low intensity and more white light at maximum intensity.

Product info

DESCRIPTION

Cylinder rail set in white for Global 1-ignition, complete with 1 meter rail and two spotlights. The spotlights are supplied with integrated LED -module and adapter, ready for direct mounting on the rail. Dim-to-Warm from 3000K to 2000K provides gradually warmer color temperature when dimming. CRI 95 provides correct color rendering. Light output per spot is 1100 lumens at tc=25, beam angle 38°. Lifetime L80B10 100,000 hours.

Luminaire height 220 mm and diameter 60 mm. The spots can be angled 90° and rotated 350°, and can be moved along the rail if necessary without switching. System power per spot 15W, LED -current 350 mA. Operating voltage 230V 50Hz. Dimming via phase section. IP20 and insulation class I.

The track set can be expanded with extra spotlights or longer tracks if needed. Suitable for residential, cottage and commercial environments with requirements for flexible lighting control and stable operation.

Included in the package are:
2 pcs. Cylinder 60 LED track spotlight, white
1 pc. Global 1-ignition spot rail, 1 meter (GB2100-3)
1 pc. Global end piece (GB11-3)
1 pc. Global power supply (GB11-3)

Need more light? Expand your installation with one or more additional spotlights. See the accessories tab below.

Documentation

SPECIFICATIONS

Product

IP rating

IP20

Color

White

Width [mm]

60

Height [mm]

220

Lifetime [h]

L80B10: 100,000

ASSEMBLY / CONNECTION

Connection

Rail Single-circuit

LIGHTING

Lumen LED (tc=25)

850

Color temperature [K]

3000-2000K D2W

Color rendering [CRI/Ra]

95

Color code

930

Light source

LED (built-in)

ELECTRICAL DATA

Dimming type

Phase section

Voltage [V]

230V 50Hz

Insulation class

1

Base

NOW

System power [W]

15

Luminous efficacy [lm/W]

1100

Strøm LED [mA]

350
