Choose between black or white color
3000K or 4000K
Suitable for hole size Ø195-230mm
The NDL240-B is an elegant rehab lighting product ideal for use in corridors, offices, shops and hotels to create a comfortable atmosphere. With an impressive CRI, CCT and lumens per watt, the NDL240-B provides high-quality lighting that meets various needs. The product has an optimal size with a cut-out diameter of Ø195-230mm, making it ideal for replacing older rehabilitation lighting.
Variant-specific documents are available under details in the overview below.
IP rating
IP44
Lifetime [h]
L80B10: 100,000
Operating temperature [°C]
-20 - 45
Light source
LED (built-in)
Optics
Clear
Dimming type
Depending on the driver
Voltage [V]
230V 50Hz
Insulation class
2
Base
NOW
Connection
EPN0024
Recess [mm]
195-230
Assembly
Recessed, Ceiling
Art. No. 102793-2-60-2
Power [W]:
25
Lumen LED (Tc=25):
2800
Kelvin [K]:
3000
CRI [>]:
90
Light spread [°]:
60°
Color:
Black
Diffuser:
Clear
Lighting control:
EPN0024
102793-2-60-2
25
2800
3000
90
60°
Black
Clear
EPN0024
The NDL240-B is an elegant rehab lighting product ideal for use in corridors, offices, shops and hotels to create a comfortable atmosphere. With an impressive CRI, CCT and lumens per watt, the NDL240-B provides high-quality lighting that meets various needs. The product has an optimal size with a cut-out diameter of Ø195-230mm, making it ideal for replacing older rehabilitation lighting.
IP rating
IP44
Vandal class
IK06
Color
Black
Length [mm]
240
Width [mm]
240
Height [mm]
142
Diameter [mm]
240
Weight [kg]
0.93
Material
Aluminum
Lifetime [h]
L80B10: 100,000
Operating temperature [°C]
-20 - 45
Lumen out [lm]
2600
Lumen LED (tc=25)
2800
Spreading angle [°]
60°
Color temperature [K]
3000
Color rendering [CRI/Ra]
90
Color code
930
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Depending on the driver
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
2
Base
NOW
System power [W]
25
Luminous efficacy [lm/W]
102
Strøm LED [mA]
650
Voltage out, min. [V]
30
Voltage out, max. [V]
40
Connection
EPN0024
Recess [mm]
195-230
Assembly
Recessed, Ceiling
Art. No. 102793-2-60-3
Power [W]:
25
Lumen LED (Tc=25):
2800
Kelvin [K]:
3000
CRI [>]:
90
Light spread [°]:
60°
Color:
White
Diffuser:
Clear
Lighting control:
EPN0024
102793-2-60-3
25
2800
3000
90
60°
White
Clear
EPN0024
The NDL240-B is an elegant rehab lighting product ideal for use in corridors, offices, shops and hotels to create a comfortable atmosphere. With an impressive CRI, CCT and lumens per watt, the NDL240-B provides high-quality lighting that meets various needs. The product has an optimal size with a cut-out diameter of Ø195-230mm, making it ideal for replacing older rehabilitation lighting.
IP rating
IP44
Vandal class
IK06
Color
White
Length [mm]
240
Width [mm]
240
Height [mm]
142
Diameter [mm]
240
Weight [kg]
0.93
Material
Aluminum
Lifetime [h]
L80B10: 100,000
Operating temperature [°C]
-20 - 45
Lumen out [lm]
2600
Lumen LED (tc=25)
2800
Spreading angle [°]
60°
Color temperature [K]
3000
Color rendering [CRI/Ra]
90
Color code
930
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Depending on the driver
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
2
Base
NOW
System power [W]
25
Luminous efficacy [lm/W]
102
Strøm LED [mA]
650
Voltage out, min. [V]
30
Voltage out, max. [V]
40
Connection
EPN0024
Recess [mm]
195-230
Assembly
Recessed, Ceiling
Art. No. 102794-2-60-2
Power [W]:
25
Lumen LED (Tc=25):
3000
Kelvin [K]:
4000
CRI [>]:
90
Light spread [°]:
60°
Color:
Black
Diffuser:
Clear
Lighting control:
EPN0024
102794-2-60-2
25
3000
4000
90
60°
Black
Clear
EPN0024
The NDL240-B is an elegant rehab lighting product ideal for use in corridors, offices, shops and hotels to create a comfortable atmosphere. With an impressive CRI, CCT and lumens per watt, the NDL240-B provides high-quality lighting that meets various needs. The product has an optimal size with a cut-out diameter of Ø195-230mm, making it ideal for replacing older rehabilitation lighting.
IP rating
IP44
Vandal class
IK06
Color
Black
Length [mm]
240
Width [mm]
240
Height [mm]
142
Diameter [mm]
240
Weight [kg]
0.93
Material
Aluminum
Lifetime [h]
L80B10: 100,000
Operating temperature [°C]
-20 - 45
Lumen out [lm]
2800
Lumen LED (tc=25)
3000
Spreading angle [°]
60°
Color temperature [K]
4000
Color rendering [CRI/Ra]
90
Color code
940
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Depending on the driver
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
2
Base
NOW
System power [W]
25
Luminous efficacy [lm/W]
110
Strøm LED [mA]
650
Voltage out, min. [V]
30
Voltage out, max. [V]
40
Connection
EPN0024
Recess [mm]
195-230
Assembly
Recessed, Ceiling
Art. No. 102794-2-60-3
Power [W]:
25
Lumen LED (Tc=25):
3000
Kelvin [K]:
4000
CRI [>]:
90
Light spread [°]:
60°
Color:
White
Diffuser:
Clear
Lighting control:
EPN0024
102794-2-60-3
25
3000
4000
90
60°
White
Clear
EPN0024
The NDL240-B is an elegant rehab lighting product ideal for use in corridors, offices, shops and hotels to create a comfortable atmosphere. With an impressive CRI, CCT and lumens per watt, the NDL240-B provides high-quality lighting that meets various needs. The product has an optimal size with a cut-out diameter of Ø195-230mm, making it ideal for replacing older rehabilitation lighting.
IP rating
IP44
Vandal class
IK06
Color
White
Length [mm]
240
Width [mm]
240
Height [mm]
142
Diameter [mm]
240
Weight [kg]
0.93
Material
Aluminum
Lifetime [h]
L80B10: 100,000
Operating temperature [°C]
-20 - 45
Lumen out [lm]
2800
Lumen LED (tc=25)
3000
Spreading angle [°]
60°
Color temperature [K]
4000
Color rendering [CRI/Ra]
90
Color code
940
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Depending on the driver
Flicker-free
Yes
Voltage [V]
230V 50Hz
Insulation class
2
Base
NOW
System power [W]
25
Luminous efficacy [lm/W]
110
Strøm LED [mA]
650
Voltage out, min. [V]
30
Voltage out, max. [V]
40
Connection
EPN0024
Recess [mm]
195-230
Assembly
Recessed, Ceiling
