Tania Mini Slim Basic is a thin recessed spotlight that is rotatable and tiltable. It is ideal for use in restaurants, cafés, hotels, shops and showrooms, but is equally suitable for homes and cottages.
Comes with phasecut dimming. Comes in both white and black.
Variant-specific documents are available under details in the overview below.
IP rating
IP 20
Height [mm]
142
Diameter [mm]
42
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Light source
LED (built-in)
Optics
Clear
Insulation class
2
Connection
Terminal
Recess [mm]
Ø35
Assembly
Recessed, Ceiling
Art. No. 101920 - 36 - 2 -p
Power [W]:
9
Lumens LED (Tc=25):
850
Kelvin [K]:
2700
CRI [>]:
90
Light spread [°]:
36°
Color:
Black
Diffuser:
Clear
Lighting control:
Terminal
101920 - 36 - 2 -p
9
850
2700
90
36°
Black
Clear
Terminal
Assortment status: In stock
Tania Mini Slim Basic is a thin recessed spotlight that is rotatable and tiltable. It is ideal for use in restaurants, cafés, hotels, shops and showrooms, but is equally suitable for homes and cottages.
Comes with phasecut dimming. Comes in both white and black.
IP rating
IP 20
Color
Black
Height [mm]
142
Diameter [mm]
42
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Operating temperature [°C]
- 20 - 40
Lumen out [lm]
681
Lumens LED (tc=25)
850
Spreading angle [°]
36°
Color temperature [K]
2700
Color rendering [CRI/Ra]
90
Color code
927
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Phase section
Voltage [V]
230V 50Hz
Insulation class
2
System power [W]
9
Luminous efficacy [lm/W]
83
Max. load per course - B10
125
Max. load per course - B16
200
Max. load per course - C10
125
Max. load per course - C16
200
Starting current Imax [A]
5
Starting current time [µs]
100
Voltage out, min. [V]
32.3
Voltage out, max. [V]
38.1
Connection
Terminal
Recess [mm]
Ø35
Assembly
Recessed, Ceiling
Art. No. 101920 - 36 - 3 -p
Power [W]:
9
Lumens LED (Tc=25):
850
Kelvin [K]:
2700
CRI [>]:
90
Light spread [°]:
36°
Color:
White
Diffuser:
Clear
Lighting control:
Terminal
101920 - 36 - 3 -p
9
850
2700
90
36°
White
Clear
Terminal
Assortment status: In stock
Tania Mini Slim Basic is a thin recessed spotlight that is rotatable and tiltable. It is ideal for use in restaurants, cafés, hotels, shops and showrooms, but is equally suitable for homes and cottages.
Comes with phasecut dimming. Comes in both white and black.
IP rating
IP 20
Color
White
Height [mm]
142
Diameter [mm]
42
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Operating temperature [°C]
- 20 - 40
Lumen out [lm]
695
Lumens LED (tc=25)
850
Spreading angle [°]
36°
Color temperature [K]
2700
Color rendering [CRI/Ra]
90
Color code
927
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Phase section
Voltage [V]
230V 50Hz
Insulation class
2
System power [W]
9
Luminous efficacy [lm/W]
84
Max. load per course - B10
125
Max. load per course - B16
200
Max. load per course - C10
125
Max. load per course - C16
200
Starting current Imax [A]
5
Starting current time [µs]
100
Voltage out, min. [V]
32.3
Voltage out, max. [V]
38.1
Connection
Terminal
Recess [mm]
Ø35
Assembly
Recessed, Ceiling
Art. No. 101921 - 36 - 2 -p
Power [W]:
9
Lumens LED (Tc=25):
850
Kelvin [K]:
3000
CRI [>]:
90
Light spread [°]:
36°
Color:
Black
Diffuser:
Clear
Lighting control:
Terminal
101921 - 36 - 2 -p
9
850
3000
90
36°
Black
Clear
Terminal
Assortment status: In stock
Tania Mini Slim Basic is a thin recessed spotlight that is rotatable and tiltable. It is ideal for use in restaurants, cafés, hotels, shops and showrooms, but is equally suitable for homes and cottages.
Comes with phasecut dimming. Comes in both white and black.
IP rating
IP 20
Color
Black
Height [mm]
142
Diameter [mm]
42
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Operating temperature [°C]
- 20 - 40
Lumen out [lm]
740
Lumens LED (tc=25)
850
Spreading angle [°]
36°
Color temperature [K]
3000
Color rendering [CRI/Ra]
90
Color code
930
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Phase section
Voltage [V]
230V 50Hz
Insulation class
2
System power [W]
9
Luminous efficacy [lm/W]
90
Max. load per course - B10
125
Max. load per course - B16
200
Max. load per course - C10
125
Max. load per course - C16
200
Starting current Imax [A]
5
Starting current time [µs]
100
Voltage out, min. [V]
32.3
Voltage out, max. [V]
38.1
Connection
Terminal
Recess [mm]
Ø35
Assembly
Recessed, Ceiling
Art. No. 101921 - 36 - 3 -p
Power [W]:
9
Lumens LED (Tc=25):
850
Kelvin [K]:
3000
CRI [>]:
90
Light spread [°]:
36°
Color:
White
Diffuser:
Clear
Lighting control:
Terminal
101921 - 36 - 3 -p
9
850
3000
90
36°
White
Clear
Terminal
Assortment status: In stock
Tania Mini Slim Basic is a thin recessed spotlight that is rotatable and tiltable. It is ideal for use in restaurants, cafés, hotels, shops and showrooms, but is equally suitable for homes and cottages.
Comes with phasecut dimming. Comes in both white and black.
IP rating
IP 20
Color
White
Height [mm]
142
Diameter [mm]
42
Material
Aluminum
Lifetime [h]
L 80 B 10 : 100000
Operating temperature [°C]
- 20 - 40
Lumen out [lm]
764
Lumens LED (tc=25)
850
Spreading angle [°]
36°
Color temperature [K]
3000
Color rendering [CRI/Ra]
90
Color code
930
Color Tolerance [SDCM]
3
Light source
LED (built-in)
Optics
Clear
Dimming type
Phase section
Voltage [V]
230V 50Hz
Insulation class
2
System power [W]
9
Luminous efficacy [lm/W]
90
Max. load per course - B10
125
Max. load per course - B16
200
Max. load per course - C10
125
Max. load per course - C16
200
Starting current Imax [A]
5
Starting current time [µs]
100
Voltage out, min. [V]
32.3
Voltage out, max. [V]
38.1
Connection
Terminal
Recess [mm]
Ø35
Assembly
Recessed, Ceiling
