Product info
SPECIFICATIONS
Product
Ingress Protection
IP20
Length [mm]
120
Width [mm]
45
Height [mm]
28
Weight [kg]
0.15
Operating Temperature [°C]
-20 - 50
Driver Data
Ingress Protection
IP20
System Power [W]
18
Dimming
Faseavsnitt
Dimming, Minimum Level [%]
1
Protection Class
2
CC or CV
CC
CC [mA]
350 -
Max. output voltage [V]
62
Output Current Tolerance [%]
5
Current Ripple [%]
15
Current Setting
None
Expected Lifetime [h]
50000
ELECTRICAL DATA
Dimming
Phase-Cut
System Voltage [V]
230V 50Hz
Protection Class
2
Max. Load pr. circuit - B10
35
Max. Load pr. circuit - B16
56
Max. Load pr. circuit - C10
74
Max. Load pr. circuit - C16
118
Leakage current [mA]
5
Inrush current Imax [A]
5
Inrush current time [µs]
300
Manufacturer Data
Manufacturer
AcTEC
