Product info
SPECIFICATIONS
Product
IP rating
IP20
Color
White
Width [mm]
400
Height [mm]
30
Weight [kg]
1.62
Lifetime [h]
L80B10: 100,000
Operating temperature [°C]
-10 - 40
LIGHTING
Lumen out [lm]
3421
Lumen LED (tc=25)
3500
Spreading angle [°]
90°
Color temperature [K]
3000
Color rendering [CRI/Ra]
80
Color code
830
Light source
LED (built-in)
Optics
Opal
ELECTRICAL DATA
Dimming type
Depending on the driver
Voltage [V]
230V 50Hz
Insulation class
1
Max power, light source [W]
Ledbuiltin
System power [W]
35
Luminous efficacy [lm/W]
98
Strøm LED [mA]
900
Voltage out, min. [V]
33
Voltage out, max. [V]
38
ASSEMBLY / CONNECTION
Connection
Depending on driver
Recess [mm]
360
Assembly
Recessed, Ceiling
