DESCRIPTION
Skat is very suitable for installation at ground level and provides a unique light pattern against the wall. This 180° fan-shaped light pattern is very effective and creates an inviting atmosphere outdoors.
Skat 330lm 830 4° 6W Quickconnect Dark Grey
- Outdoor ground lamp
- 180° fan-shaped slide
- QuickConnect for easy installation
Product data sheet
Product info
Mounting
Documentation
SPECIFICATIONS
Product
IP rating
IP65
Vandal class
IK08
Color
Dark gray
Length [mm]
140
Width [mm]
62
Height [mm]
95
Weight [kg]
0.64
Operating temperature [°C]
-20 - 50
LIGHTING
Lumen LED (tc=25)
330
Spreading angle [°]
4°
Color temperature [K]
3000
Color rendering [CRI/Ra]
80
Color code
830
Optics
Clear
ELECTRICAL DATA
Dimming type
No
Voltage [V]
230V 50Hz
Insulation class
1
Base
NOW
System power [W]
6
Luminous efficacy [lm/W]
15
Leakage current [mA]
0.5
Starting current Imax [A]
10
Strøm LED [mA]
500
Voltage out, min. [V]
9
Voltage out, max. [V]
10
ASSEMBLY / CONNECTION
Connection
Quick coupling
Mounting
Surface-mounted, Ground
