Ufo B High Bay 25.000lm 865 (6500K) 120° 150W 1-10V 18i3, sort

  • 25,000 lumens – daylight 6500K, great for detailing and automotive environments

  • 1–10V dimming and wide 120° light distribution

  • Robust fixture with 5m cable and 18i3 plug

Read more

Category: Tag:
CE markedIP65: IP6x is the highest level of protection against mechanical ingress (objects/dust). Very suitable for outdoor use.IK08: Protection against impact equivalent to 1.7kg from a height of 300mm.Insulation class 1: Must be connected to ground.Application: Indoor

Product info

DESCRIPTION

Ufo B High Bay is a powerful and efficient industrial light designed for demanding environments with high mounting points. With a whopping 25,000 lumens, 150W of power and a color temperature of 6500K (865), it delivers a bright daylight that is great for environments where details count. The wide light distribution of 120° ensures even lighting without dark zones.

This luminaire is particularly well suited for detailing, car preparation and use in paint booths , where correct light reproduction is essential for a perfect result. Robust design in black finish, 1–10V dimming for flexible control, and 5 meter cable with 18i3 plug make installation easy and reliable.

Documentation

SPECIFICATIONS

Product

IP rating

IP65

Vandal class

IK08

Color

Black

Width [mm]

300

Height [mm]

116

Weight [kg]

2.65

Material

Aluminum

Lifetime [h]

L80B50: 91,000

Operating temperature [°C]

-35 - 50

LIGHTING

Lumen out [lm]

24300

Lumen LED (tc=25)

25000

Spreading angle [°]

120

Color temperature [K]

6500

Color rendering [CRI/Ra]

80

Color code

865

Light source

LED (built-in)

Optics

Lens

ELECTRICAL DATA

Dimming type

PWM, 1-10V

Voltage [V]

230V 50Hz

Insulation class

1

System power [W]

150

Luminous efficacy [lm/W]

162

ASSEMBLY / CONNECTION

Connection

18i3 5m + 2x0.4m Open end

Assembly

Suspended
