LED-Strips 14,4W/m

  • 2700K, 3000K or 4000K
  • CRI>90
  • IP20 or IP65
Read more

Show variants
Category:

Product info

DESCRIPTION

LED-stripe av meget høy kvalitet. Leveres i varianter med fargetemperatur på 2700K, 3000K eller 4000K. For utendørs montering eller baderom har vi varianter med IP65. CRI på 90 sikrer korrekt fargegjengivelse, som er viktig f.eks. for belysning ved speil på baderom. LED-stripen kommer i lengder på 5 meter og har en effekt på 14,4W/m. For kjøling og best utseende anbefaler vi å montere LED-striper i en aluminiumsprofil. Se tilbehør for driveralternativer.

Documents

Family data sheet All files (.ZIP)

Variant-specific documents are available under details in the overview below.

SPECIFICATIONS

Product

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

MacAdam [SDCM]

3

ELECTRICAL DATA

System Voltage [V]

24VDC

VARIANT SELECTION

CCT [K]
Ingress Protection
LED pr. meter
Lumen pr/m
Art. No. CCT [K]Lumen LED (tc=25)Ingress ProtectionLED pr. meterColorLens DifuserMax Width LedstripLumen pr/m
Energy label

LED-Strips 14,4W/m

Art. No. SC-2835IP3-2700

CCT [K]:

2700

Ingress Protection:

IP20

LED pr. meter:

120

Lumen pr/m:

1100

SC-2835IP3-2700

2700

IP20

120

1100

Item status: Stock item

DOCUMENTATION

CE markedIP20: Indoor useInsulation class 3Areas of use: IndoorVoltage: 24 volt

Product

Ingress Protection

IP20

Length [mm]

5000

Width [mm]

10

Weight [kg]

0.15

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Beam angle [°]

120°

CCT (Color Temperature) [K]

2700

CRI/Ra

90

Color Code

927

MacAdam [SDCM]

3

LED pr. meter

120

MOUNTING / CONNECTION

Connection

Kabel 2m

Heat sink needed

No

Cuttable [mm]

50

Max. length [m]

5

ELECTRICAL DATA

Dimming

Depending on Driver

System Voltage [V]

24VDC

Protection Class

3

System Power [W/m]

14.4

Luminous Efficacy [lm/W]

77

LED-Strips 14,4W/m

Art. No. SC-2835IP3-3000

CCT [K]:

3000

Ingress Protection:

IP20

LED pr. meter:

120

Lumen pr/m:

1200

SC-2835IP3-3000

3000

IP20

120

1200

Item status: Stock item

DOCUMENTATION

CE markedIP20: Indoor useInsulation class 3Areas of use: IndoorVoltage: 24 volt

Product

Ingress Protection

IP20

Length [mm]

5000

Width [mm]

10

Weight [kg]

0.15

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Beam angle [°]

120°

CCT (Color Temperature) [K]

3000

CRI/Ra

90

Color Code

930

MacAdam [SDCM]

3

LED pr. meter

120

MOUNTING / CONNECTION

Connection

Kabel 2m

Heat sink needed

No

Cuttable [mm]

50

ELECTRICAL DATA

Dimming

Depending on Driver

System Voltage [V]

24VDC

Protection Class

3

System Power [W/m]

14.4

Luminous Efficacy [lm/W]

83

LED-Strips 14,4W/m

Art. No. SC-2835IP3-4000

CCT [K]:

4000

Ingress Protection:

IP20

LED pr. meter:

120

Lumen pr/m:

1320

SC-2835IP3-4000

4000

IP20

120

1320

Item status: Stock item

DOCUMENTATION

CE markedIP20: Indoor useInsulation class 3Areas of use: IndoorVoltage: 24 volt

Product

Ingress Protection

IP20

Length [mm]

5000

Width [mm]

10

Weight [kg]

0.15

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Beam angle [°]

120

CCT (Color Temperature) [K]

4000

CRI/Ra

90

Color Code

940

MacAdam [SDCM]

3

LED pr. meter

120

MOUNTING / CONNECTION

Connection

Kabel 2m

Heat sink needed

No

Cuttable [mm]

50

ELECTRICAL DATA

Dimming

Depending on Driver

System Voltage [V]

24VDC

Protection Class

3

System Power [W/m]

14.4

Luminous Efficacy [lm/W]

92

LED-Strips 14,4W/m

Art. No. SC-2835IP3S-2700-24

CCT [K]:

2700

Ingress Protection:

IP65

LED pr. meter:

120

Lumen pr/m:

1110

SC-2835IP3S-2700-24

2700

IP65

120

1110

Item status: Stock item

DOCUMENTATION

CE marked Insulation class 3Areas of use: IndoorVoltage: 24 volt

Product

Ingress Protection

IP65

Length [mm]

5000

Width [mm]

12.5

Height [mm]

4

Weight [kg]

0.15

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Beam angle [°]

120

CCT (Color Temperature) [K]

2700

CRI/Ra

90

Color Code

927

MacAdam [SDCM]

3

LED pr. meter

120

MOUNTING / CONNECTION

Connection

Kabel 2m

Heat sink needed

No

Cuttable [mm]

50

ELECTRICAL DATA

Dimming

Depending on Driver

System Voltage [V]

24VDC

Protection Class

3

System Power [W/m]

14.4

Luminous Efficacy [lm/W]

77

LED-Strips 14,4W/m

Art. No. SC-2835IP3S-3000-24

CCT [K]:

3000

Ingress Protection:

IP65

LED pr. meter:

120

Lumen pr/m:

1200

SC-2835IP3S-3000-24

3000

IP65

120

1200

Item status: Stock item

DOCUMENTATION

CE marked Insulation class 3Areas of use: IndoorVoltage: 24 volt

Product

Ingress Protection

IP65

Length [mm]

5000

Width [mm]

12.5

Height [mm]

4

Weight [kg]

0.15

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Beam angle [°]

120

CCT (Color Temperature) [K]

3000

CRI/Ra

90

Color Code

930

MacAdam [SDCM]

3

LED pr. meter

120

MOUNTING / CONNECTION

Connection

Kabel 2m

Heat sink needed

No

Cuttable [mm]

50

ELECTRICAL DATA

Dimming

Depending on Driver

System Voltage [V]

24VDC

Protection Class

3

System Power [W/m]

14.4

Luminous Efficacy [lm/W]

83

LED-Strips 14,4W/m

Art. No. SC-2835IP3S-4000-24

CCT [K]:

4000

Ingress Protection:

IP65

LED pr. meter:

120

Lumen pr/m:

1320

SC-2835IP3S-4000-24

4000

IP65

120

1320

Item status: Stock item

DOCUMENTATION

CE marked Insulation class 3Areas of use: IndoorVoltage: 24 volt

Product

Ingress Protection

IP65

Length [mm]

5000

Width [mm]

12.5

Height [mm]

4

Weight [kg]

0.15

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Beam angle [°]

120

CCT (Color Temperature) [K]

4000

CRI/Ra

90

Color Code

940

MacAdam [SDCM]

3

LED pr. meter

120

MOUNTING / CONNECTION

Connection

Kabel 2m

Heat sink needed

No

Cuttable [mm]

50

ELECTRICAL DATA

Dimming

Depending on Driver

System Voltage [V]

24VDC

Protection Class

3

System Power [W/m]

14.4

Luminous Efficacy [lm/W]

92

LED-Strips 14,4W/m

Art. No. SC-EP2835-4000-2-24

CCT [K]:

4000

Ingress Protection:

IP20

LED pr. meter:

60

Lumen pr/m:

1320

SC-EP2835-4000-2-24

4000

IP20

60

1320

Item status: Order item

DOCUMENTATION

CE markedIP20: Indoor useInsulation class 3Areas of use: IndoorVoltage: 24 volt

Product

Ingress Protection

IP20

Length [mm]

5000

Width [mm]

10

Weight [kg]

0.15

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Beam angle [°]

120

CCT (Color Temperature) [K]

4000

CRI/Ra

90

Color Code

940

MacAdam [SDCM]

3

LED pr. meter

60

MOUNTING / CONNECTION

Connection

Kabel 2m

Heat sink needed

No

Cuttable [mm]

100

Max. length [m]

5

ELECTRICAL DATA

Dimming

Depending on Driver

System Voltage [V]

24VDC

Protection Class

3

System Power [W/m]

14.4

Luminous Efficacy [lm/W]

92
