Aram Maxi Single Square Base

Read more

Show variants
CE markedIP20: Indoor use

Product info

Documents

Family data sheet Manufacturers Datasheet All files (.ZIP)

Variant-specific documents are available under details in the overview below.

SPECIFICATIONS

Product

Ingress Protection

IP20

Length [mm]

130

Width [mm]

130

Height [mm]

145

Weight [kg]

1.3

Lifetime [h]

L80B10: 50 000

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

System Voltage [V]

230V 50Hz

Protection Class

2

System Power [W]

28

Max. Load pr. circuit - B10

14

Max. Load pr. circuit - B16

24

Max. Load pr. circuit - C10

24

Max. Load pr. circuit - C16

40

Inrush current Imax [A]

25

Inrush current time [µs]

200

Forward Current LED [mA]

700

MOUNTING / CONNECTION

Cut-out [mm]

Ø120

Mounting

Recessed

VARIANT SELECTION

CRI [>]
Beam Angle°
Color
Art. No. CRI [>]Beam Angle°Color
Energy label

Aram Maxi Single Square Base

Art. No. 40831-7-20-2

CRI [>]:

90

Beam Angle°:

20°

Color:

Black

40831-7-20-2

90

20°

Black

Product

Ingress Protection

IP20

Color

Black

Length [mm]

130

Width [mm]

130

Height [mm]

145

Weight [kg]

1.3

Lifetime [h]

L80B10: 50 000

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Lumen out [lm]

3200

Lumen LED (tc=25)

3550

Beam angle [°]

20°

CCT (Color Temperature) [K]

3000

CRI/Ra

90

Color Code

930

MacAdam [SDCM]

3

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

None

System Voltage [V]

230V 50Hz

Protection Class

2

System Power [W]

28

Luminous Efficacy [lm/W]

114

Max. Load pr. circuit - B10

14

Max. Load pr. circuit - B16

24

Max. Load pr. circuit - C10

24

Max. Load pr. circuit - C16

40

Inrush current Imax [A]

25

Inrush current time [µs]

200

Forward Current LED [mA]

700

Voltage forward, Min. [V]

29.3

Voltage forward, Max. [V]

38.7

MOUNTING / CONNECTION

Connection

18i3 Quick connection

Cut-out [mm]

Ø120

Mounting

Recessed

Aram Maxi Single Square Base

Art. No. 40831-7-20-3

CRI [>]:

90

Beam Angle°:

20°

Color:

White

40831-7-20-3

90

20°

White

Product

Ingress Protection

IP20

Color

White

Length [mm]

130

Width [mm]

130

Height [mm]

145

Weight [kg]

1.3

Lifetime [h]

L80B10: 50 000

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Lumen out [lm]

3200

Lumen LED (tc=25)

3550

Beam angle [°]

20°

CCT (Color Temperature) [K]

3000

CRI/Ra

90

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

None

System Voltage [V]

230V 50Hz

Protection Class

2

System Power [W]

28

Luminous Efficacy [lm/W]

114

Max. Load pr. circuit - B10

14

Max. Load pr. circuit - B16

24

Max. Load pr. circuit - C10

24

Max. Load pr. circuit - C16

40

Inrush current Imax [A]

25

Inrush current time [µs]

200

Forward Current LED [mA]

700

Voltage forward, Min. [V]

29.3

Voltage forward, Max. [V]

38.7

MOUNTING / CONNECTION

Connection

18i3 Quick connection

Cut-out [mm]

Ø120

Mounting

Recessed

Aram Maxi Single Square Base

Art. No. 40831-7-30-2

CRI [>]:

90

Beam Angle°:

30°

Color:

Black

40831-7-30-2

90

30°

Black

Product

Ingress Protection

IP20

Color

Black

Length [mm]

130

Width [mm]

130

Height [mm]

145

Weight [kg]

1.3

Lifetime [h]

L80B10: 50 000

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Lumen out [lm]

3037

Lumen LED (tc=25)

3550

Beam angle [°]

30°

CCT (Color Temperature) [K]

3000

CRI/Ra

90

Color Code

930

MacAdam [SDCM]

3

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

None

System Voltage [V]

230V 50Hz

Protection Class

2

System Power [W]

28

Luminous Efficacy [lm/W]

108

Max. Load pr. circuit - B10

14

Max. Load pr. circuit - B16

24

Max. Load pr. circuit - C10

24

Max. Load pr. circuit - C16

40

Inrush current Imax [A]

25

Inrush current time [µs]

200

Forward Current LED [mA]

700

Voltage forward, Min. [V]

29.3

Voltage forward, Max. [V]

38.7

MOUNTING / CONNECTION

Connection

18i3 Quick connection

Cut-out [mm]

Ø120

Mounting

Recessed

Aram Maxi Single Square Base

Art. No. 40831-7-30-3

CRI [>]:

80

Beam Angle°:

30°

Color:

White

40831-7-30-3

80

30°

White

Product

Ingress Protection

IP20

Color

White

Length [mm]

130

Width [mm]

130

Height [mm]

145

Weight [kg]

1.3

Lifetime [h]

L80B10: 50 000

Operating Temperature [°C]

-20 - 50

LIGHT TECHNICAL

Lumen out [lm]

3037

Lumen LED (tc=25)

3550

Beam angle [°]

30°

CCT (Color Temperature) [K]

3000

CRI/Ra

80

Color Code

830

MacAdam [SDCM]

3

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

None

System Voltage [V]

230V 50Hz

Protection Class

2

System Power [W]

28

Luminous Efficacy [lm/W]

108

Max. Load pr. circuit - B10

14

Max. Load pr. circuit - B16

24

Max. Load pr. circuit - C10

24

Max. Load pr. circuit - C16

40

Inrush current Imax [A]

25

Inrush current time [µs]

200

Forward Current LED [mA]

700

Voltage forward, Min. [V]

29.3

Voltage forward, Max. [V]

38.7

MOUNTING / CONNECTION

Connection

18i3 Quick connection

Cut-out [mm]

Ø120

Mounting

Recessed
