High Bay

Read more

Show variants
Category:
CE markedIP40:Insulation class 1: Shall be connected to earth.Areas of use: Indoor

Product info

Documents

Family data sheet All files (.ZIP)

Variant-specific documents are available under details in the overview below.

SPECIFICATIONS

Product

Ingress Protection

IP40

Lifetime [h]

L80B10: 50 000

LIGHT TECHNICAL

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

None

System Voltage [V]

230V 50Hz

Protection Class

1

Socket / Cap-Base

N/A

MOUNTING / CONNECTION

Mounting

Suspended, Ceiling, Pendant

VARIANT SELECTION

Effect [W]
Lumen LED (tc=25)
Beam Angle°
Color
Art. No. Effect [W]Lumen LED (tc=25)Beam Angle°ColorLength [mm]
Energy label

High Bay

Art. No. 02030-2-45-1

Effect [W]:

32

Lumen LED (tc=25):

4250

Beam Angle°:

45°

Color:

Grey

02030-2-45-1

32

4250

45°

Grey

Item status: Stock item

DIMENSIONS AND LIGHT DISTRIBUTION

DOCUMENTATION

CE markedIP40:Insulation class 1: Shall be connected to earth.Areas of use: Indoor

Product

Ingress Protection

IP40

Color

Grey

Width [mm]

320

Height [mm]

450

Lifetime [h]

L80B10: 50 000

LIGHT TECHNICAL

Lumen out [lm]

3843

Lumen LED (tc=25)

4250

Beam angle [°]

45°

CCT (Color Temperature) [K]

3000

CRI/Ra

80

Color Code

830

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

None

System Voltage [V]

230V 50Hz

Protection Class

1

Socket / Cap-Base

N/A

System Power [W]

32

Luminous Efficacy [lm/W]

123

MOUNTING / CONNECTION

Connection

18i3 Quick connection

Mounting

Suspended, Ceiling, Pendant

High Bay

Art. No. 02030-2-45-5

Effect [W]:

32

Lumen LED (tc=25):

4250

Beam Angle°:

45°

Color:

Green

02030-2-45-5

32

4250

45°

Green

Item status: Stock item

DIMENSIONS AND LIGHT DISTRIBUTION

DOCUMENTATION

CE markedIP40:Insulation class 1: Shall be connected to earth.Areas of use: Indoor

Product

Ingress Protection

IP40

Color

Green

Width [mm]

320

Height [mm]

450

Weight [kg]

2.7

Lifetime [h]

L80B10: 50 000

LIGHT TECHNICAL

Lumen out [lm]

3843

Lumen LED (tc=25)

4250

Beam angle [°]

45°

CCT (Color Temperature) [K]

3000

CRI/Ra

80

Color Code

830

MacAdam [SDCM]

3

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

None

System Voltage [V]

230V 50Hz

Protection Class

1

Socket / Cap-Base

N/A

System Power [W]

32

Luminous Efficacy [lm/W]

123

Voltage forward, Min. [V]

30.6

Voltage forward, Max. [V]

39.2

MOUNTING / CONNECTION

Connection

18i3 Quick connection

Mounting

Suspended, Ceiling, Pendant

High Bay

Art. No. 02050-2-30-1

Effect [W]:

46

Lumen LED (tc=25):

5650

Beam Angle°:

30°

Color:

Grey

02050-2-30-1

46

5650

30°

Grey

Item status: Stock item

DIMENSIONS AND LIGHT DISTRIBUTION

DOCUMENTATION

CE markedIP40:Insulation class 1: Shall be connected to earth.Areas of use: Indoor

Product

Ingress Protection

IP40

Color

Grey

Width [mm]

430

Height [mm]

505

Weight [kg]

5

Lifetime [h]

L80B10: 50 000

LIGHT TECHNICAL

Lumen out [lm]

5341

Lumen LED (tc=25)

5650

Beam angle [°]

30°

CCT (Color Temperature) [K]

3000

CRI/Ra

80

Color Code

830

MacAdam [SDCM]

3

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

None

System Voltage [V]

230V 50Hz

Protection Class

1

Socket / Cap-Base

N/A

System Power [W]

46

Luminous Efficacy [lm/W]

116

Max. Load pr. circuit - B10

18

Max. Load pr. circuit - B16

30

Max. Load pr. circuit - C10

31

Max. Load pr. circuit - C16

51

Inrush current Imax [A]

18

Inrush current time [µs]

250

Voltage forward, Min. [V]

30.6

Voltage forward, Max. [V]

39.3

MOUNTING / CONNECTION

Connection

18i3 Quick connection

Mounting

Suspended, Ceiling, Pendant

High Bay

Art. No. 02050-2-60-1

Effect [W]:

46

Lumen LED (tc=25):

5650

Beam Angle°:

60°

Color:

Grey

02050-2-60-1

46

5650

60°

Grey

Item status: Stock item

DIMENSIONS AND LIGHT DISTRIBUTION

DOCUMENTATION

CE markedIP20: Indoor useInsulation class 1: Shall be connected to earth.Areas of use: Indoor

Product

Ingress Protection

IP20

Color

Grey

Width [mm]

430

Height [mm]

505

Weight [kg]

5

Lifetime [h]

L80B10: 50 000

LIGHT TECHNICAL

Lumen out [lm]

5150

Lumen LED (tc=25)

5650

Beam angle [°]

60°

CCT (Color Temperature) [K]

3000

CRI/Ra

80

Color Code

830

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

None

System Voltage [V]

230V 50Hz

Protection Class

1

Socket / Cap-Base

N/A

System Power [W]

46

Luminous Efficacy [lm/W]

112

Max. Load pr. circuit - B10

18

Max. Load pr. circuit - B16

30

Max. Load pr. circuit - C10

31

Max. Load pr. circuit - C16

51

Inrush current Imax [A]

18

Inrush current time [µs]

250

Forward Current LED [mA]

1050

MOUNTING / CONNECTION

Connection

18i3 Quick connection

Mounting

Suspended, Ceiling, Pendant
