Make D2W 45-950lm 930-919 34° 9,4W WH w/o driver

  • Square design
  • Dim2Warm (3000K-1900K)
  • Cut-out Ø86x86mm
Read more
SKU: 11080-D2W-34-3 Item status: Stock item Category: Tag:
CE markedIP20: Indoor useInsulation class 3Areas of use: IndoorDim2Warm

Product info

DESCRIPTION

Make is a square downlight in singel version that comes with Dim 2 Warm function. The color temperature (K) can be adjusted between 3000K and 1900K through dimming.

Driver is not included and sold separately. See accessories for recommended drivers.

Documents

SPECIFICATIONS

Product

Ingress Protection

IP20

Color

White

Length [mm]

92

Width [mm]

92

Height [mm]

107

LIGHT TECHNICAL

Lumen LED (tc=25)

45-950

Beam angle [°]

34°

CCT (Color Temperature) [K]

3000-1900K D2W

CRI/Ra

90

Color Code

930-919

MacAdam [SDCM]

3

Lightsource type

LED (built in)

Lens (Diffuser)

Clear

ELECTRICAL DATA

Dimming

Depending on Driver

System Voltage [V]

230V 50Hz

Protection Class

3

Socket / Cap-Base

N/A

System Power [W]

9,4

Forward Current LED [mA]

500

MOUNTING / CONNECTION

Connection

Depending on driver

Cut-out [mm]

86X86

Mounting

Recessed, Ceiling
